Thyristor Based CNC Plasma Cutting Machine KALI-150HD
  CNC Plasma Cutting Machine -> KALI-150HD
Plasma Cutting Machines
  CNC Cutting Systems
  •   Miniature Type
  •   Gantry Type
  •   Pipe Profile
  CNC Plasma Cutting Machine
  •   KALI-HD Series
  •  KALI-150HD
  •  KALI-200HD
  •  KALI-400HD
  •  KALI-500HD
  •  KALI-45iHD
  •  KALI-80iHD
  •  KALI-100iHD
  •  KALI-200iHD
  •  KALI-300iHD
  Manual Plasma Cutting Machine
  •   KALI-F Series
  •   KALI-H Series
  •   KALI-I Series

CNC Compatible Air Plasma Cutting System:

KALI-150HD is plasma cutting machine with 30-200 amperes output current range. It can cut upto 50mm pierce cut and 75mm edge cut of any electro conductive metal plate like Stainless Steel, Mild Steel, Copper, Brass, Aluminium, Inconel, Monel, Titanium, Nickel, Chrome, Bronze, Galvanized Steel, Heated Steel, Wear Plates & Castings etc.
It is heavy duty, rugged machine suitable fot both workshop & project sites.

Special Features:

• 100% Indian Product.
• Post Cutting operations such as grinding of dross etc. almost eliminated.
• Safety interlocks against over heating of power source, transformer and failure of air pressure.
• Almost all parts of the torch are replaceable hence least maintainance cost.
• Power Source is designed for continuous operation.
• Best quality Input Power Ratio.
• Highest Consumables Life.
• Unique torch designs for manual & machanised operation.
• Possible to vary the current as per requirement.
• Comfortable for operator as current can be adjusted to suit his skill
• More suitable for integration with CNC profile cutting systems.

Technical Specification Of KALI-150HD:

Input : 3 Phase, 415Volts± 15%, 50 Hertz
Open Circuit Voltage : 330 Volts
Output Current Range :  30-200 AMPS
Max Power Output :  30 KW
Cutting Range (Pierce/Edge) : 35/75 mm
Insulation Class : “H”
Power Source Cooling  :  Forced Air
Torch Cooling  :  Water
Suitability with plasma gases  :  Oil Free Compressed Air, Argon, Nitrogen, Argon+H2

Standard Scope of Supply:

• Heavy Duty Water Cooling & Circulating Unit with Water Tank, Radiator and Cooling Fan.
• Water cooled Air Plasma Cutting CNC Torch.
• Electrode - 5 Sets.
• Nozzles - 5 Sets.
• 'O' Ring - 5 Sets.

Spares & Consumables available for the machine KALI-150HD:

• Nozzle.
• Electrode.
• Front Cap.
• Contact Tube.
• Electrode Holder.
• Nozzle Holder.
