Features
- Power source built around Inverter technology with highly stable welding Arc & precision low current pilot Arcing.
- Machine is ready to use for operation with controls for gas Pre-flow, gas Post-flow, Up slope & Down slope.
- Selectable Pilot current upto 10A.
- Machine is capable of adapting external compact & portable water chilling unit.
- All torches are supplied with accessories like contact tips, nozzles, ceramic sleeves collets of different sizes.
- Argon Regulator & Hose pipe will be supplied with the machine.
Technical Specifications
- Input Supply – 230 Volts ± 15%, 50 Hz, Single Phase AC
- Open Circuit Voltage – 100 VDC (Max.)
- Output Current Range – 1 – 25 Amps
- Amp Increase / Decrease – +/- 0.1 Amp
- Power source cooling – Forced Air
- Insulation – Class H
- Protection – IP21
- Micro TIG torch specs
- Current capacity – 1 – 25 Amps
- Cooling – Gas cooled
- Cable length – 4 Meters
- Micro Plasma Torch
- Current capacity – 1 – 25 Amps
- Cooling – Chilled Water
- Cable length – 4 Meters
Optional Accessories
- Micro Plasma torches are available in 8 meters length
- TIG torches are available in 8 meters length
Scope of Supply
- MPW 25 Plasma welding source
- Inbuilt Water chiller unit for torch cooling
- Micro Plasma / TIG torch – 4 meters
- Input cable 5 mtrs. of suitable size
- Earthing cable 5 mtrs. with clamp
Consumables
- Micro Plasma torch electrode
- Micro Plasma torch nozzle
Spares
- TIG torch spares
- Micro Plasma torch spares
