TECHNICAL SPECIFICATIONS for SOLARIS 250 TIG
- Input Supply – 3 phase – 400 Volts ± 10%, 50 / 60 Hz
- Input kVA @100% duty cycle – 4.10
- Input Current @100% duty cycle – 6
- Current Range – 3 – 250 Amps
- Open Circuit Voltage – 70 – 80 Volts
- Welding Current – Duty cycle is calculated at 10 mins
- @60% duty cycle – 250 Amps
- @100% duty cycle – 192 Amps
- Protection Class – IP 23
- Class of Insulation – H
- Power Factor – Better than 0.90
- Efficiency – Better than 0.90
- Power source cooling – Forced Air
- High Frequency unit – Electronic Circuitry
- Torch cooling – Gas cooled
STANDARD SCOPE OF SUPPLY
- Gas Hose pipe 5 mtrs.
- Argon flow meter
- Regulator
- TIG torch 3 mtrs.
OPTIONAL ACCESSORIES
- Welding cable with lugs
- Welding Electrode Holder
- Earthing cable with clamp
- Input cable for power source
